The CB1.8 is a 1.8 metric ton utility roller with 1000 mm (39 in) tandem vibratory drums.
Cat
CB1.8 Utility Compactor
Overview
Photos
Videos
360° View
Exterior
360° Exterior View. Double click on the image to zoom in on any area of the product.
Interior
360° Interior View. Double click on the image to zoom in on any area of the product.
Features
Specifications
-
Weights
Spec Value Operating Weight 3825 lb -
Operating Specifications
Spec Value Standard Compaction Width 39 in Curb Clearance 16 in Ground Clearance 10 in Travel Speed - Maximum 5.3 mile/h Static Linear Load 63 lb/in Turning Radius - Inside Drum Edge 75 in -
Engine
Spec Value Gross Power 24.7 hp Engine Model Cat C1.1 -
Dimensions
Spec Value Overall Length 80 in Overall Width 44 in Drum Diameter 22.5 in Drum Width 39 in Maximum Machine Height 94.5 in -
Vibratory System
Spec Value Frequency 3420 V/m Nominal Amplitude - High 0.018 in Centrifugal Force per Drum - Maximum 3057 lb -
Service Refill Capacities
Spec Value Fuel Tank Capacity 7.9 gal (US) Water Spray Tank Capacity 38 gal (US)
Standard Equipment
Operator Environment
- ROPS Folding
- Operator Console w/ Emergency Stop, Simple Rocker Switches, and Machine Warning Indicator Lights
- Dual 12-volt Power Outlet
- Horn, Backup Alarm
Compaction System
- Folding Scrapers
- Vibe Selection - Front, Rear, or Both
- Pressurized, Triple-Filtration Spray System
Powertrain
- Air Cleaner, Dual Element
- Engine Belt Guard
Technology
- ProductLinkTM
Electrical
- Working Lights
Other
- Vandal Protection - Lockable Hood and Controls Cover
- Machine Life and Tiedowns
Optional Equipment
Operator Environment
- Adjustable Suspension Seat w/ Operator Presence Switch
- ROPS Fixed
Electrical
- Battery Disconnect
- Roading Lights
- Rotating Amber Beacon
- Light Guards
Other
- Single Point Lift
