The 50” (1270 mm) split front drum enables the outer half of the drum to rotate faster than the inner half resulting in quick work on corners and curves, without mat tearing.
| Spec | Value |
|---|---|
| Base Weight | 20,160 lb |
| Max Weight | 26,580 lb |
| Width | 5' 4" |
| Length | 15' 6" |
| Height | 8' 11" |
| Wheelbase | 132' |
| Front Drum Diameter | 40" |
| Front Drum Width | 50" |
| Rear Drum Diameter | 53" |
| Rear Drum Width | 50" |
| Maximum Turn Angle | 45° |
| Inside Turning Radius | 12' 6" |
| Low Range Max Speed | 5.25 mph |
| High Range Max Speed | 10.5 mph |
| Water Tank Capacity | 200 gal |
| Fuel Tank Capacity | 42 gal |
