Condition

• GENERAL CONDITION

  Item	Condition
  Machine Starts and is Operable	Yes
  Visible Oil Leaks	Yes
  Body	●●●
  Frame	●●●
  General	●●

• GENERAL APPEARANCE

  Item	Condition
  Bumper	●● LEFT REAR SIDE BUMPER BENT.
  Car Body	●●
  Counterweight	●●
  Draw Bar	●●●
  Eng. Enclose Hood / Stack	●● RADIATOR & PUMP DOORS MINOR BENDS.
  Fuel Tank	●●●
  Grab Irons	●●
  Hood	●● ONE HOOD LATCH IS BROKEN.
  Main Frame Welds	●●●
  Paint	●●
  Sheet Metal	●●
  Steps / Ladder	●●

• SAFETY ITEMS

  Item	Condition
  ROPS	No NON-ROPS CAB.
  Horn	●●●
  Seat Belt / Date	●●
  Travel Alarm	●

• OPERATOR STATION

  Item	Condition
  Cab Filter / Heat Vent Louvres	●
  Dash Console	●
  Door Latches / Hinges / Seals	●● SEALS ARE POOR
  Gauges	●● AFTERMARKET WATER TEMP GAUGE SINCE THE ORIGINAL DOESN'T WORK.
  Heater / Defroster	●
  Hour Meter - GAUGES, OPERATION STATION, CONSOLE	●● READS 3,201 HRS SO FRAME HRS ARE 13,201 HRS.
  Hydraulic Controls	●●
  Interior Lights	●
  Monitoring Display	●●
  Seat Cushions / Suspension / Type	●●
  Switches	●
  Travel Controls (Type)	●●
  Windows	●●
  Windshield Wipers	●

• ENGINE

  Item	Condition
  Blow By	Yes HIGH BLOWBY.
  Fuel Leaks	Yes LEVEL 2 FUEL FILTER MOUNTS LEAK.
  Knocking	No
  Oil Leaks	Yes LEVEL3 FRONT COVER AND REAR COVER LEAKS. VALVE COVER LEAK AS WELL.
  Water in Oil	No
  Notes - ENGINE	THE ENGINE IS RUNNING SMOOTH WITH THICK BLUE SMOKE, HIGH BLOWBY AND OIL LEAKS.
  Oil Pressure (H/L/N)	FAIR
  Smoke Color (B/D/L/W)	THICK BLUE SMOKE.
  Belts / Pulleys - ENGINE	●●
  Engine Oil Level / Condition	●●●
  Engine Supports / Mounts	●●●
  Exhaust / Muffler / Stack	●●
  Fuel Injection System	●●
  Governor	●●
  Intake / Air Filters	●●●
  Operating Condition - ENGINE	●●
  Turbocharger / Blower	●●

• COOLING SYSTEM

  Item	Condition
  Compression in Radiator	No
  Coolant Leaks	No
  Oil in Anti-Freeze	No
  Standard Radiator	Yes
  Notes - COOLING SYSTEM	THE COOLING SYSTEM WORKS IN 20 DEGREE WEATHER.
  Anti-Freeze Level / Color / Condition	●● NORMAL COLOR & LEVEL.
  Belts / Pulleys - COOLING SYSTEM	●●
  Coolers	●●
  Fan	●●
  Fan Drive / Type	●●
  Fan Shrouds / Guards	●●
  Hoses / Tubes	●●
  Radiator	●●
  Water Pump	●●

• ELECTRICAL, STARTING AND CHARGING SYSTEM

  Item	Condition
  Alternator	●●●
  Batteries / Cables / Master Disconnect	●●
  Lighting	●● BOOM LIGHT IS OUT.
  Starter	●●●
  Wiring	●●

• HYDRAULICS

  Item	Condition
  Notes - HYDRAULICS	THE HYDRAULICS FUNCTION WITH A MINOR WINE AND MANY LEAKS.
  Boom Cylinder	● 3/32 INCH PLAY IN THE BOOM CYLINDER HEAD END JOINTS. THE R.H. LEAKS TO LEVEL 1 & L.H. TO LEVEL 2
  Bucket Cylinder	●●●
  Control Linkage	●● THE PILOT CONTROL VALVE ARE BOTH LEAKING LEVEL 1.
  Hose Lines	● LEVEL 3 LEAKS.
  Hydraulic Swivel	●●
  Operating Condition - HYDRAULICS	●●
  Pump Drive	●●
  Pumps & Valves	●● PUMPS HAVE LEVEL 2 LEAKS
  Stick Cylinder	● LEVEL 3 LEAK.
  Swing Gear	●● PLAY IN THE SWING GEAR.
  Swing Motors	●●
  Tank	●●●
  Travel Motors	●●

• BOOM

  Item	Condition
  Boom Length (Actual Length)	19 FOOT 5 INCHES.
  Notes - BOOM	THE BOOM MOUNT HAS 3/32-1/14 INCH PLAY.
  Boom Condition	●● CRACK DEVELOPING ON THE R.H. SIDE OF BOOM BY ARCH.
  Boom Pins	●●
  Pins & Bushings - BOOM	●

• STICK

  Item	Condition
  Notes - STICK	THE BOOM TO STICK JOINT HAS EXCESSIVE PLAY.
  Stick Length	11 FOOT 10 INCHES
  Pins & Bushings - STICK	●
  Stick Conditions	●●
  Stick Pins	●●

• BUCKET

  Item	Condition
  Quick Coupler	No
  Width	46 INCH WITH 48 INCH CUT.
  Bucket Bottom	●●
  Bucket Linkage	●● THE BUCKET LINKAGE HAS 3/32 - 1/4 INCH PLAY
  Bucket Mounts	●●●
  Bucket Sides	●●●
  Teeth / Adapters	●●●

• UNDERCARRIAGE

  Item	Condition
  Cannon	THE L.H. RECOIL IS COLLAPSED.
  Link Part Number	TREK 10-0012
  Links	SOME EXTRA PLAY IN MASTER PINS.
  Notes - UNDERCARRIAGE	COUPLE OF BOTTOM ROLLERS ARE LEAKING, THE L.H. TRACK IS COLLAPSED AND THE L.H. SPROCKET IS WORN.
  Track Shoes Width / Type	32 INCH TRIPLE GROUSER SHOES.
  Track Frame - Left	●●
  Track Frame - Right	●●
  Carrier Rollers Front	Left     Right
  Carrier Rollers Rear	Left     Right
  Idlers Front	Left     Right
  Links	Left     Right
  Pins & Bushings (External)	Left     Right
  Pins & Bushings (Internal)	Left     Right
  Segments	Left     Right
  Track Roller 9	Left     Right
  Track Shoe Grouser Height	Left     Right

• FINAL DRIVES

  Item	Condition
  Notes - FINAL DRIVES	THE OILS ARE LEVEL.
  Housings, Left	●●●
  Housings, Right	●●●
  Planetaries / Differential, Left	●●
  Planetaries / Differential, Right	●●
