Condition

• GENERAL APPEARANCE

  Item	Condition
  Notes - GENERAL APPEARANCE	THE MACHINE IS STRAIGHT & LOOKS NICE.
  Cab or Canopy	●●●
  Crankcase Guard / Battery Box	●●●
  Eng. Enclose Hood / Stack	●●●
  Fuel Tank	●●●
  Grab Irons	●●●
  Main Frame	●●●
  Paint	●●● LOOKS NICE.
  Pre-Cleaner Bowl	●●●
  Radiator Grill & Shroud	●●●
  Rear Frame	●●●
  Sheet Metal	●●●
  Steps / Ladder	●●●

• SAFETY ITEMS

  Item	Condition
  ROPS	Yes THE ROPS ARE CLEAN.
  Safety Decals In Place	Yes
  Safety Decals Legible	Yes
  Horn	●●●

• OPERATOR STATION

  Item	Condition
  Back Up Alarm	Yes
  Current O&MM	Yes
  ROPS Certification Plate	Yes CERTIFICATION IS IN PLACE.
  Air Conditioner	●●● COOLING.
  Dash Console	●●●
  Door Latches	●●●
  Floor Boards	●●●
  Gauges	●●●
  Glass/Mirrors	●●●
  Heater	●●●
  Interior Lights	●●●
  Meter	●●● ACCURATE.
  Seat Belt	●● FUNCTIONAL.
  Seat Cushion / Arm Rest	●●●
  Switches	●●●
  Windshield Wipers	●●●

• ENGINE

  Item	Condition
  Blow By	Yes MODERATE.
  Compression in Radiator	No
  Emissions Decal	Yes TIER 4 FINAL.
  Knocking	No
  Oil Leaks	No
  Water in Oil	No
  Anti-Freeze Color	NORMAL COLOR & LEVEL.
  Notes - ENGINE	THE ENGINE IS RUNNING SMOOTH AND THE SAMPLE RETURNED NORMAL.
  Oil Pressure (H/L/N)	NORMAL
  Smoke (B/D/L/W)	NORMAL
  Air Cleaners	●●●
  Belts / Pulleys	●●●
  Engine Supports	●●●
  Exhaust / Muffler	●●●
  Fuel Injection System	●●●
  Governor	●●●
  Oil Filter Condition (CUT) - ENGINE	●●● SAMPLED DURING THIS INSPECTION RETURNED NORMAL.
  Operating Condition - ENGINE	●●●
  Turbocharger / Blower	●●●

• COOLING SYSTEM

  Item	Condition
  Leaks - COOLING SYSTEM	No
  Notes - COOLING SYSTEM	THE COOLING SYSTEM IS FUNCTIONING NORMAL IN 68 DEGREE WEATHER.
  Coolers	●●●
  Fan	●●●
  Fan Drive	●●● HYDRAULIC
  Hoses	●●●
  Radiator	●●●
  Water Pump	●●●

• ELECTRICAL, STARTING AND CHARGING SYSTEM

  Item	Condition
  Block Heater	Yes
  Ether Aid	Yes
  Alternator	●●●
  Batteries / Cables	●●●
  Lighting	●●●
  Starter	●●●
  Wiring	●●●

• TRANSMISSION

  Item	Condition
  Leaks - TRANSMISSION	No
  Transmission - Noisy	No
  Notes - TRANSMISSION	THE HYSTAT IS PERFORMING NORMAL IN ALL SPEED SETTINGS.
  Controls	●●●
  Cooler	●●●
  Lines / Fittings	●●●
  Operating Condition - TRANSMISSION	●●●
  Pump - TRANSMISSION	●●●
  Seals	●●●
  Temp / Pressure Gauges	●●●

• STEERING

  Item	Condition
  Notes - STEERING	THE MACHINE IS STEERING NORMAL WITH GOOD CONTROL.
  Steering Linkage	●●●
  Steering Valves / Pumps	●●●

• BRAKE

  Item	Condition
  Control Valve	●●●
  Operating Condition - BRAKE	●●●
  Parking Brake	●●●
  Type (Pedal, Lever)	●●● PEDAL

• HYDRAULICS

  Item	Condition
  Leaks - HYDRAULICS	No
  Notes - HYDRAULICS	THE HYDRAULICS ARE FUNCTIONING NORMAL.
  Bucket & Hoist Kickout	●●●
  Control Linkage - HYDRAULICS	●●●
  Hoist Cylinder	●●●
  Hose Lines	●●●
  Overall Operating Condition	●●●
  Pumps & Valves	●●●
  Tank	●●●
  Tilt Cylinder	●●●

• BUCKET

  Item	Condition
  Notes - BUCKET	New Bucket
  Bucket Bottom	●●●
  Bucket Floor	●●●
  Bucket Linkage - BUCKET	●●● TIGHT
  Bucket Sides	●●●
  Cutting Edges	●●●
  Loader Frame	●●●
  Loader Pins & Bushings	●●●
  Teeth / Adapters	●●●

• UNDERCARRIAGE

  Item	Condition
  Equalizer Bar	TIGHT
  Link Part Number	254-9699 SYSTEM ONE
  Notes - UNDERCARRIAGE	THE U/C IS IN FUNCTIONAL CONDITION.
  Pivot Shaft	DRY
  Track Shoes	22 INCH DOUBLE GROUSER SHOES.
  Track Frame - Left	●●●
  Track Frame - Right	●●●
  Carrier Rollers Front	Left     Right
  Carrier Rollers Rear	Left     Right
  Idlers Front	Left     Right
  Links	Left     Right
  Pins & Bushings (External)	Left     Right
  Segments	Left     Right
  Track Roller 7	Left     Right
  Track Shoes (Width)	Left     Right

• FINAL DRIVES

  Item	Condition
  Notes - FINAL DRIVES	BOTH DRIVE OILS ARE LEVEL WITH NORMAL APPEARING MAGNETS.
  Housings, Left	●●●
  Housings, Right	●●●
  Planetaries, Left	●●●
  Planetaries, Right	●●●

• COMMENTS, MISC. REPAIRS, GENERAL REMARKS

  Item	Condition
  comment 1	THE MACHINE HAS NORMAL PERFORMANCE AND OPERATION WITH SMOOTH RUNNING ENGINE WITH A NORMAL SAMPLE RETURN. THE HYSTAT IS PERFORMING NORMAL. THE LINKAGES ARE TIGHT.
