Available with either a soil or combination rotor powered by a dual planetary drive motors with a max drum speed of 150 rpm. The 78” (1981 mm) wide drum has a max working depth of 14” (355 mm).
Specifications
Units for specifications
Specifications
| Weight | 40,000 lb |
|---|---|
| Height | 11' 5" |
| Length | 27' 8" |
| Width | 8' 2" |
| Wheelbase | 129" |
| Ground Clearance | 19" |
| Engine | Cat® C9.3B Tier 4 |
| Horsepower | 375 hp |
| Max Transport Speed | 10 mph |
| Max Working Speed | 180 fpm |
| Cutting Width | 78" |
| Max Cutting Depth | 14" |
| Drum Diameter w/ Teeth | 48" |
| Max Drum Speed | 150 rpm |
| Fuel Tank Capacity | 190 gal |
| Hydraulic Tank Capacity | 90 gal |
| Front Tires | 14.9-24 8 PR |
| Rear Tires | 28LR26 165 LI |
