Pro XD Full-Size Gas

With a Polaris ProStar motor that is speed-limited for safety, puncture-resistant seats, heavy-duty, jobsite-ready tires and cab that keeps sealed when you need it to, the Pro XD Full-Size Gas is a workday asset to tow, haul or just transport your crew from one spot to the next.

  • 1000cc motor
  • 2-person cab
  • Kevlar®-backed seats

Product Disclaimer: Kubota® is a registered trademark of Kubota Corporation. Duro® is a registered trademark of HWA Fong Rubber (USA) Inc. Donaldson® is a registered trademark of Donaldson Company, Inc. Kevlar® is a registered trademark of E.I. du Pont de Nemours & Company.

Pro XD Full-Size Gas

Specifications

Units for specifications

Engine & Drivetrain

Air Intake Front Air Intake with Donaldson® Cyclonic Air Filter
Cooling Liquid
Cylinders Displacement 1,000 cc
Drive System Type On-Demand 4x4
Engine Braking System (EBS) Not Equipped
Engine Type ProStar 1,000 cc Gas
Fuel System/Battery Electronic Fuel Injection
Top Speed Adjustable to 40 mph (64 km/h)
Horsepower 39.5 HP
Transmission/Final Drive Automatic PVT H/L/N/R/P; Shaft

Dimensions

Bed Box Dimensions (L x W x H) 43.5 x 54 x 11.5 in (110.5 x 137 x 29 cm)
Box Capacity 1,250 lb (567 kg)
Estimated Dry Weight 1,573 lb (714 kg)
Fuel Capacity 11.5 gal (43.5 L)
Ground Clearance 11 in (27.9 cm)
GVWR
Hitch Towing Rating 2,500 lb (1,134 kg)
Overall Vehicle Size (L x W x H) 126 x 62.5 x 75 in (320 x 159 x 191 cm)
Payload Capacity 1,900 lbs (862 kg)
Turning Radius 112 in (284 cm)
Wheelbase 85 in (215.9 cm)

Brakes

Front/Rear Brakes 4-Wheel Hydraulic Disc with Dual-Bore Front Calipers
Parking Brake Park In-Transmission

Additional Specifications

Cargo System Lock & Ride®
Maintenance Interval 100 Hours (25 Hour initial)
Hitch Type Standard 2 in (5 cm) Receiver
Instrumentation All-Digital Gauge, Speedometer, Odometer, Tachometer, 2 Tripmeters, Hour Meter, Gear Indicator, Diff Lock Indicator, High-Temp Light, Clock, Clutch Belt Slip Warning, Glow Plug Indicator, Low Oil Pressure Indicator, and Seat Belt Indicator
Lighting 55W low/60W high, LED Tail
Other Standard Features Horn, Backup Alarm, Password protected, electronically adjustable speed limiting
Seat Covering Kevlar®-Backed Vinyl (Grey)
Person Capacity 2
Tilt Steering Standard

Tires / Wheels

Electronic Power Steering Optional
Hubs Front: Steel; Rear: Ductile Iron
Front Tires 26 x 10-12 Duro® DI-2042 Power Grip (M/T)
Rear Tires 26 x 10-12 Duro® DI-2042 Power Grip (M/T)
Wheels 12 x 6 HD Steel - Gloss Black
Front Suspension 9 in (22.9 cm)
Rear Suspension 9 in (22.9 cm)
