Engineered and built to exceed the demands of commercial paving, the Weiler P395 incorporates proven designs with new innovations to provide performance, reliability and outstanding mat quality in a wide range of applications.
Specifications
Units for specifications
Specifications
| Engine | Cat C3.6 St V |
|---|---|
| Engine HP | 120 HP |
| Length | 15' 2" |
| Width | 8' 6" |
| Truck Clearance | 19" |
| Fuel Capacity | 39 Gal |
| Hydraulic Capacity | 30 Gal |
| Spraydown Tank | 8 Gal |
| Hopper Capacity | 11 Tons |
| Machine Weight | 24,000 lbs |
| Screed Weight | 4,400 lbs |
| Paving Width | 7' 8" to 15' 4" |
| Main Plate Width | 16.5" |
| Extension Plate Width | 10" |
| Screed Heat | Electric - 4 Elements |
| Vibration | 4 x 2500 VPM |
| Steering | Steering Wheel Standard |
| Track Length | 96" |
| Transport Speed | 350 FPM |
| Max Auger Speed | 150 rpm |
| Auger Diameter | 14" |
| Generator | Hydraulic Driven |
