Features
-
Rental ready
Robust, durable product with a range of rental ready features to meet job requirements and applications.
-
Fuel/Emissions Strategy
EU Stage V.
-
Cat C4.4 Diesel Engine
Industry proven reliability.
-
XQCP Control Panel
Easy to use digital controls.
-
Cat LC3114F Generator
Automatic voltage regular for fast response in demanding applications.
-
Robust Galvanised Enclosure
Inhibits corrosion in service. Prevents water ingress, provides security and sound attenuation.
-
Sound Isolated Operator Panel
Improved operator comfort.
-
Cat Connect
Remote monitoring for fleet management and asset tracking.
-
Factory Designed, Built and Tested
Single-source Supplier
-
Worldwide Product Support
- Cat dealers have over 1,800 dealer branch stores operating in 200 countries
- Your local Cat dealer provides extensive post-sale support, including maintenance and repair agreements
-
500 hr Oil Change Intervals
Reducing operating costs and producing less waste.
-
Improved Transportability
Skid plates with drag points, Single point lifting frame, Fork lift pockets and 4 Point lift.
-
Additional Options Available
Distribution sockets. Extended Service interval kits.
Specifications
Units for specifications
Generator Set
| Rating Prime | 115 kVA |
|---|---|
| Frequency | 50/60 Hz |
| Voltage | 220 - 480 V |
| Fuel/Emissions Strategy | EU Stage V |
Engine
| Engine | Cat® C4.4 |
|---|---|
| Fuel | Diesel |
| Emissions | EU Stage V |
Dimensions
| Width | 45 in 1150 mm |
|---|---|
| Height | 82 in 2076 mm |
| Length | 117 in 2970 mm |
| Weight - With Lube Oil and Coolant | 4579 lb 2077 kg |
Fuel Consumption
| 100% Load 50 Hz | 7.2 gal/hr 27.3 l/hr |
|---|---|
| 100% Load 60 Hz | 7.4 gal/hr 28 l/hr |
| 75% Load 50 Hz | 5.3 gal/hr 20.4 l/hr |
| 75% Load 60 Hz | 5.5 gal/hr 21 l/hr |
Noise rating (with enclosure)
| Sound Power @ 1 meters (3 feet) @ 75% of rating (50Hz) | 75.3 dB(A) |
|---|---|
| Sound Power @ 1 meters (3 feet) @ 75% of rating (60Hz) | 78.9 dB(A) |
Standard Equipment
Cat® C4.4 Diesel Engine
- Twin Turbocharged, air-to-air aftercooler
- Electronic ECM controlled
After Treatment
- Engine Mounted Clean Emissions Module (CEM)
- Diesel Emissions Fluid (DEF)
Alternator
- LC3114F Frame
- Coastal insulation protection
Control Panel
- XQCP set mounted digital controller
Air Filter
- Air cleaner, cyclonic/paper with dust cup and serviceindicator
Cat Connect remote monitoring
- Provides package monitoring and management
Cooling System
- Package mounted radiator with vertical air discharge. Filled from factory
- High ambient performance
Charging / Starting System
- 12V, heavy duty charging alternator with integral regulator and belt guards
Fuel System
- 24 hour dual wall fuel tank with internal fuel fill
- Engine mounted primary and secondary fuel filter
Distribution
- Separate robust steel enclosures for control & distribution sections
- 4 pole, 200A main circuit breaker
Enclosure
- Sound attenuating, galvanised steel enclosure with exceptional noise reduction performance
- Sealed quarter-turn compression latches with key orpadlock capabilities
Lube Oil
- On engine primary and secondary oil filters. Filled from factory
General
- Factory tested and inspected
- Full manufacturer's warranty
Optional Equipment
Distribution
- CE socket box with integrated MCB & RCBO protection
Fuel Option Pack
- Inboard mounted 3-way valve for external fuel connection, electronic fuel gauge and Bund Level Sender
Drains option Pack
- Oil and coolant drains piped to base frame
