Caterpillar is leading the power generation marketplace with Power Solutions engineered to deliver unmatched flexibility, expandability, reliability, and cost-effectiveness.
Features
-
Cat Diesel Engine
-
SR5 Alternator
-
Worldwide Product Support
-
Full Range of Attachments
Specifications
Units for specifications
Generator Set Specifications
| Maximum Rating | 1820 ekW (60Hz), 2425 kVA (50Hz) |
|---|---|
| Minimum Rating | 1650 ekW (60Hz), 2200 kVA (50Hz) |
| Emissions/Fuel Strategy | IMO Tier 2 |
| Frequency | 50 / 60 Hz |
| Speed | 900 / 1000 rpm |
| Duty Cycle | Prime, Continuous |
Engine Specifications
| Engine Model | C280-6, I-6,4-Stroke Water-Cooled Diesel |
|---|---|
| Bore | 11 in 280 mm |
| Stroke | 11.8 in 300 mm |
| Displacement | 111 in³ 6762 l |
| Compression Ratio | 13:01 |
| Aspiration | TA |
| Fuel System | Direct unit injection |
| Governor Type | Generator Set Monitoring System (GMS) |
Generator Set Dimensions
| Length - Maximum | 404 in 10261.7 mm |
|---|---|
| Width - Maximum | 99.62 in 2530.3 mm |
| Height - Maximum | 156.6 in 3977.7 mm |
| Dry Weight - Genset (maximum) | 74970 lb 34070 kg |
Standard Equipment
Air Inlet System <!-- 3600 series only -->
- Air inlet shutoff
- Aftercooler, fresh water, corrosion resistant coated (air side)
- Turbocharger, watercooled (720 rpm and HFO), engine oil lubricated
- Breather, crankcase, top-mounted
Cooling System
- Water temperature regulator
- Engine coolant water drains
- Jacket water thermostats
Exhaust System
- Includes adapter, flexible exhaust fitting
- Dry, gas tight, exhaust manifold
- 457 mm (18 in) Cat bolt pattern
Fuel System
- Simplex or duplex
Generator System
- Custom generator per generator data sheet completed by dealer
Governor System
- UG Actuator
Lube System
- Wet oil sump. Includes engine-driven main lubrication and oil pumps, oil lines and oil pan
- Centrifugal oil filters with single shutoff
- Service side engine mounted on cylinder block inspection covers
- Crankcase explosion relief valves
- Oil filler and dipstick
- Oil pressure regulating valve
Mounting System
- Damper, torsional vibration
- Engine and generator mounting
Starting / Charging System
- Vane type air starter
- Line group for single point custom connection
- Air silencer
- One motor, engine mounted at rear, on left side
General:
- Gear driven pumps: Fuel/oil/jacket water/aftercooler/Oil cooler water
- Paint, Caterpillar yellow
Optional Equipment
Air Inlet System
- Air inlet adapter
- Soot filter
- Heavy duty air cleaner
- Boost control valve
- Air cleaner louver assembly
- Air cleaner
- Vertical support bracket
Cooling System
- Auxiliary water pump
- Cooling system aids
- Heating aids
- Expansion tank
Exhaust System
- Weld flange and related hardware
- Flexible exhaust fittings
Fuel System
- Fuel system connections
- Fuel priming pump
- Duplex primary fuel strainer
Generator System
- Class F insulation
- 3 Phase, six Leads, WYE
- Busbar connections
- Winding temperature detectors
- Anti-condensation space heaters
Governor System
- 723 Plus
- Digital programmers
- Electronic/actuators
- Battery backup/power supply
- 2301 A load share
- EGB actuator
Lube System
- Oil pan drain valve
- Lube ANSI adapter (Emergency connection)
Mounting System
- Isolator
- Spring type vibration isolators
- Non-vertically restrained
- Vertically restrained
Starting / Charging System
- Pressure reducing valve
- Compressed air flex hose
General:
- Custom paint colors
