Standard Equipment

ELECTRICAL

• 12 volt Electrical System
• 80 ampere Alternator
• Ignition Key Start/Stop Switch
• Lights: Gauge Backlighting, Two Rear Tail Lights, Two Rear Halogen Working Lights, Two Adjustable Front Halogen Lights, Dome Light
• Backup Alarm
• Heavy Duty Battery, 850 CCA

OPERATOR ENVIRONMENT

• Advanced Display with Rearview Camera: Full Color, 127 mm (5 in) LCD screen; Advanced Multi-operator Security System; On-screen Adjustments for Implement Response, Hystat Response and Creep Control
• Gauges: Fuel Level, Hour Meter
• Operator Warning System Indicators: Air Filter Restriction, Alternator Output, Armrest Raised/Operator Out of Seat, Engine Coolant Temperature, Engine Oil Pressure, Glow Plug Activation, Hydraulic Filter Restriction, Hydraulic Oil Temperature, Park Brake Engaged, Engine Emission System
• Adjustable Vinyl Seat
• Fold In Ergonomic Contoured Armrest
• Control Interlock System, when operator leaves seat or armrest raised: Hydraulic System Disables, Hydrostatic Transmission Disables, Parking Brake Engages
• ROPS Cab, Open, Tilt Up
• FOPS, Level I
• Top and Rear Windows
• Floor Mat
• Interior Rearview Mirror
• 12 volt Electric Socket
• Horn
• Hand (Dial) Throttle, Electronic
• Adjustable Joystick Controls
• Anti-theft Security System with 6-button Keypad
• Storage Compartment with Netting

POWER TRAIN

• Cat C3.3B, Turbo Diesel Engine, Meeting Tier 4 Final and Stage V Emission Standards
• Air Cleaner, Dual Element, Radial Seal
• S·O·SSM Sampling Valve, Hydraulic Oil
• Filters, Cartridge-type, Hydraulic
• Filters, Canister-type, Fuel and Water Separator
• Radiator/Hydraulic Oil Cooler (side-by-side)
• Spring Applied, Hydraulically Released Parking Brakes
• Hydrostatic Transmission
• Four Wheel Chain Drive

OTHER

• Engine Enclosure, Lockable
• Extended Life Antifreeze, –37° C (–34° F)
• Machine Tie Down Points (6)
• Support, Lift Arm
• Hydraulic Oil Level Sight Gauge
• Radiator Coolant Level Sight Gauge
• Radiator, Expansion Bottle
• Cat ToughGuard™ Hose
• Auxiliary, Hydraulics, Continuous Flow
• Heavy Duty, Flat Faced Quick Disconnects with Integrated Pressure Release
• Split D-Ring to Route Work Tool Hoses Along Side of Left Lift Arm
• Electrical Outlet, Beacon
• Belly Pan Cleanout
• Variable Speed Demand Fan
• Product Link™ PL240, Cellular

MANDATORY EQUIPMENT

• Hydraulics, Standard or High Flow XPS
• Quick Coupler, Mechanical or Powered
• High Visibility Seat Belt, 50 mm (2 in) or 75 mm (3 in)
• Power Train: One Speed, One Speed with Ride Control, Two Speed or Two Speed with Ride Control
• PERFORMANCE PACKAGES:
  – Performance Package H1: Standard Flow Hydraulics (No Self Level)
  – Performance Package H2: Standard Flow, Dual Direction Electronic Self Level (Raise and Lower), Work Tool Return to Dig, Work Tool Positioner, and Electronic Snubbing (Raise and Lower)
  – Performance Package H3: High Flow XPS, Dual Direction Electronic Self Level (Raise and Lower), Work Tool Return to Dig, Work Tool Positioner, and Electronic Snubbing (Raise and Lower)
• COMFORT PACKAGES:
  – Open ROPS (C0): Static Seat (No Foot Throttle, Headliner, Heater or Door)
  – Open ROPS (C1): Foot Throttle, Headliner, Cup Holder, and choice of Seat (Mechanical Suspension or High Back, Heated, Air Ride Seat) (No Heater or Door)
  – Enclosed ROPS with Heater (C2): Foot Throttle, Headliner, Heater and Defroster, Side Windows, Cup Holder, Radio Ready, choice of Seat (Mechanical Suspension or High Back, Heated, Air Ride Seat) and Door (Glass or Polycarbonate)
  – Enclosed ROPS with A/C (C3): C2 + Air Conditioner
